CNC router machine WATTSAN M1 2030
Unique selling proposition
-
Bed with pre-annealing
-
Reinforced portal
-
Increased thickness of housing
-
Showroom and Demo
-
Framed structure
Brief of CNC Router Machine WATTSAN M1 2030
CNC router machine Wattsan M1 2030 — capacity and large production volumes
The CNC router machine WATTSAN M1 2030 is a model designed for cutting large area materials. This machine is used for cutting and engraving wood, MDF, chipboard, acrylic, plexiglass, PVC, composite, aluminum. You can also perform 3D milling cutting on WATTSAN M1 2030.
WATTSAN M1 2030 can produce doors, cabinets, tables, chairs, machine parts and gaskets made of paronite, bases for stands, LED signs and light boxes, souvenirs and three-dimensional relief on wood.
The WATTSAN M1 2030 large format machine has a large working area of 2000x3000x300 mm with a lattice table top. The M-series machines can be include with a vacuum table, which allows you to quickly fix the sheet material on the table surface. The design includes a 6 kW spindle with an ER-32 collet chuck. An air cooling system and a built-in vacuum cleaner for collecting chips and dust are also available for an additional fee.
Materials
-
Brass
-
Paronite
-
Copper
-
Aluminium
-
MDF
-
Plexiglass (Acrylic)
-
Foam rubber
-
Plastic
-
Chipboard
-
Plywood
-
Wood
Wattsan machine beds will provide for 7 years of machine continuous operation
-
Annealing of the bed
The solid-cast machine bed provides the required level of rigidity and vibration resistance. For the durability of the machine frame structure we anneal it in a special furnace for stress relief. Furnace tempering guarantees the service life of the frame for more than 10 years.
-
Two-phase stepper motors
These motors are responsible for the machine movement along the Y, X and Z axes. Such motors usually do not break down and are easily replaced. At the request of the customer, the machine is equipped with a stepper motor, a hybrid stepper motor or a servo motor.
-
Massive machine bed
On the M1 series machine, unlike A1, the bed is reinforced and has a thickness of 10 mm, which gives high strength and stability of the frame structure and provides 10 years of work without distortion and deformation. And the stiffeners increase the stability of the frame and its tensile strength.
-
Reinforced portal
The portal side pillars have increased rigidity to allow working with heavy loads, and also ensure the absence of vibrations when working at high speeds. It allows you to use from 1 to 12 spindles, depending on the machine design.
-
Planetary gear
Milling machines of the M series are equipped with Shimpo planetary gearboxes. They are designed to work with high loads, converting the torque from the servo motor and transferring it to the skew gear, which drives the portal movement. It is used in machines for cutting hard wood and soft metals.
-
Vacuum table
The M-series machines can be included with a vacuum table, which allows you to quickly fix the sheet material on the table surface. Due to the hard pull, the vacuum table not only fixes, but also aligns thin-sheet materials. For a high-quality result of work, it is very important that the surface of the processed material is smooth.
-
HIWIN guides
Wattsan machines are equipped with HIWIN guides. They are distinguished by their quality and reliability, unlike analogues. Four closed rows of bearings are 30% superior to similar designs in terms of load capacity and rigidity.
Firm frame structure of Wattsan machines
During the machine operation inertia of gentry motion is transferred to the frame which is subjected to significant loads. Therefore material and structure of the machine play a significant role in securing the machine against deformation and breakage.
-
All frames undergo multi-stage heat treatment within a day followed by milling. Furnace annealing guarantees a frame service life of more than 7 years.
-
All-welded frame of steel profile provides the right level of rigidity and vibration resistance. High strength and resistance of the frame ensure 10 years of operation without distortion and deformation.
Purchase procedure
-
Equipment selection
We assist you in making your choice of a machine matching your needs
-
Sending invoice
We agree on the complete set of the machine and sending the invoice with the final cost of the equipment.
-
Payment
In full if the machine is in stock. 50% in advance 50% at the delivery if the machine is not in stock.
-
We check the machine
The 3 step quality control: at the Wattsan factory, at our warehouse in the Netherlands, before the delivery.
-
Delivery or pick-up
Either a transport company or you pick up the machine from our warehouse.
-
Launching equipment
We are here to assist you whenever you need support.
Experiences from enthusiastic bloggers and clients
-
I recently purchased the Wattsan metal cutter, and I am thoroughly impressed. Customer support was very helpful throughout the process.
Oliver Martin
-
This laser engraver can engrave without any problem. How fast and easy it is able to customize products!
Riccardo Muscarella
-
The Wattsan metal cutter exceeded my expectations. It’s very precise and easy to operate. Perfect for my workshop projects. Delivery was smooth, and customer service was very responsive. A great investment!
Emma Rossi
-
Machine has a perfectly flat surface. It makes repetitive work easier for me!
Matteo Moras
-
Fantastic quality and performance! The Wattsan metal cutter is powerful and reliable, making my work much more efficient. I’m very happy with this purchase. Highly recommended!
Lucas Schmidt
-
Great job done within an hour. Thanks to the speed of the laser CO2 machine.
Roberto D'Adago
-
This model is great, and laser precision is crazy, it’s sharp as a razor!
Roger Jungo
Technical characteristics
Included kit
-
Wrench set
-
Clamp set
-
Milling bits set
-
Collet set
-
NC studio PCI-card
-
NC studio connection cable
-
Aspiration system adapter
-
Fuse kit
-
USB cable
-
Power cable
