Fiber metal cutting machine WATTSAN 2060 HARD ULTRA

Working area:: 2000x4000/2000x6000/2000x8500 mm
Laser power:: 20000-120000 W
Max. movement speed:: 100/120 m/min

Eficient smoke extraction
Triple frame protection
Protective cabin with air filtration
2 surveillance cameras
3 years warranty on the emitter

Fiber Metal Cutting Machine WATTSAN 2060 HARD ULTRA slide 1
Fiber Metal Cutting Machine WATTSAN 2060 HARD ULTRA slide 2
Fiber Metal Cutting Machine WATTSAN 2060 HARD ULTRA slide 3
Fiber Metal Cutting Machine WATTSAN 2060 HARD ULTRA slide 4
Fiber Metal Cutting Machine WATTSAN 2060 HARD ULTRA slide 5
Fiber Metal Cutting Machine WATTSAN 2060 HARD ULTRA slide 6
Fiber Metal Cutting Machine WATTSAN 2060 HARD ULTRA slide 7
Fiber Metal Cutting Machine WATTSAN 2060 HARD ULTRA slide 8
Fiber Metal Cutting Machine WATTSAN 2060 HARD ULTRA slide 9
Fiber Metal Cutting Machine WATTSAN 2060 HARD ULTRA slide 10
Fiber Metal Cutting Machine WATTSAN 2060 HARD ULTRA slide 11
Fiber Metal Cutting Machine WATTSAN 2060 HARD ULTRA slide 12
Fiber Metal Cutting Machine WATTSAN 2060 HARD ULTRA slide 13
Fiber Metal Cutting Machine WATTSAN 2060 HARD ULTRA slide 14

The Wattsan Ultra HARD Fiber Metal Cutter is an advanced, high-tech machine designed for efficiency and ease of maintenance.

Its compact design minimizes space usage, making it an ideal solution for optimizing workshop layouts.With a laser sources from 20 to 120 kW, this model delivers powerful cutting performance while maintaining low operational costs. It enhances both productivity and safety, providing an economical and effective solution for a wide range of metal cutting applications. A combination of technology and the best solutions in one!

Materials

– cutting

Carbon steel
Stainless steel
Galvanized steel
Aluminium
Copper
Brass
Titanium

Adjust the cutting process for your production

CYPCUT software has simple user-oriented controls. The implemented functions greatly simplify and optimize the cutting process.

FLYCUT
RINGCUT
NESTING
EDGESEEK
MICRO JOINT
COEDGE

FLYCUT technology allows you to determine the shortest and most efficient cutting trajectory enabling fast cutting of round and rectangular holes in sheet metal with thicknesses up to 1 mm. In this case the laser head works without lifting and lowering which ensures high speed of work and saves gas. This mode is suitable if you are manufacturing ventilation systems.
Prevents corners from melting and increases the quality of manufactured products due to the laser head looping at each corner and not stopping. The obtained corners are clear and even. RINGCUT function is suitable for working with thicker materials or for cutting products with multiple corners where precision is important, e.g. gears, monograms, souvenirs, etc.
Professional optimization of the arrangement of parts on the sheet suitable for the production of promotional products. NESTING function allows to lay out parts on the sheet as efficiently and as close to each other as possible so that there are no gaps. This allows saving material.
Allows to precisely determine the position of the sheet in the work area using three reference points. You can only put the material on the work area, specify its dimensions in the program and the machine will do everything itself. You do not need to put the material perfectly on the table.
It is used to insert micro-joints into the processing path so that the parts do not land on its side. In this case it is easy to remove the parts after cutting. This saves working head from colliding with parts during operation. This function allows producing small parts for promotional and souvenir products without losing them in the work area.
This mode allows to join lines that are close to each other, that is to join them so that the laser head does not cut in the same place. This function will greatly improve performance and reduce the operation time. This function is suitable for mass production, for example, while manufacturing workpieces, promotional and souvenir products, etc.

Metal cutters from Wattsan — forget about repairs and downtime

Precise design

In the process of designing the machine, various tests of static and dynamic loads were carried out to identify the maximum permissible deformations of the table and the bed in order to preserve the correct geometry of the structure. Due to the selected configuration, the maximum load on the table is increased by 800 kg of distributed weight. This allows processing materials up to 15 mm thick, with a 24/7 cutting accuracy of +-0.01 mm ,and ensures the durability of the bed up to 10 years.
Machine portal

Wattsan HARD machines use portals made of aluminum with an extra large cross-section. Aluminum portal with extra large cross-section is a good hardness and rigidity with light weight, as well as resistance against corrosion and oxidative processes. All this guarantees a long term and trouble-free operation.
Robust bed

Wattsan Hard frames have state-of-the-art design. Their main task is to prevent vibration when working at designed speeds and accelerations. The Wattsan Hard heat-treated steel base with stiffeners has a metal thickness of 15-18 mm, which ensures the "indestructibility" of the frame, service life over 10 years and trouble-free operation.
Protective cabin

The module with a cabin is designed to protect against reflected radiation and sparks during cutting. The cabin can be installed on any Wattsan metal cutter. And according to safety regulations, the cabin should be installed on machines with an emitter power of 2000 watts or more.
Triple frame protection

Refractory tiles are installed for protection of the transverse stiffeners inside the frame from heating and damage. The frame surface is protected by a special graphite and ceramic coating, as well as copper plates to prevent deformation of the bed from the thermal effects of the laser beam.
Double protection of the guides

Wattsan machines are equipped with a special metal protection of the machine corrugated surface to further maintain the cleanliness of the sliding guides, saving time and money for replacing the dust cover.
Loading rollers

Several ball bearings on the working table make it easier the sheet loading onto the table. The rollers can be mounted on the front, back or side of the machine as desired. The roller is lifted above the cutting table in such a way as to ensure optimal feeding. One of the most important advantages of this feeding system is the prevention of scratches on the material.

Firm frame structure of Wattsan machines

During the machine operation inertia of gentry motion is transferred to the frame which is subjected to significant loads. Therefore material and structure of the machine play a significant role in securing the machine against deformation and breakage.

E-series

Equipped with one-piece electrowelded frame and an extrusion-type gantry for high accelerations. Suitable for cutting rolled metal.

6-8 mm

Frame thickness

80 m/min

Travelling speed

Up to 1.5 kW

Laser power

Aluminium

Gantry material
S-series

The S-series gantry is reinforced with titanium ribs. Perfect for working with large volumes of production.

10-12 mm

Frame thickness

120 m/min

Travelling speed

Up to 6 kW

Laser power

Aluminium + Titanium

Gantry material
Hard version

Hard version has three layers of thermal protection. Designed for work at maximum speed and large production volumes.

>16mm

Frame thickness

Up to 210 m/min

Travelling speed

Up to 20 kW

Laser power

Aluminium + Titanium

Gantry material

Comparison table

Source power	1000 W	1500 W	3000 W	6000 W
Carbon steel (Oxygen)
Thickness, mm	Speed (m/min)
1	10	22	34	42
2	6,2	6,8	7,5	8,2
3	3	3,6	4,4	5,5
4	2,2	2,8	3,8	5
5	1,8	2,4	3,2	3,6
6	1,6	2	2,6	3,4
8	1,2	1,4	2,2	3
10	0,8	1	1,6	2,4
12		0,8	1,4	2
14		0,6	1	1,3
16			0,8	1,1
18			0,7	1
20			0,6	0,9
22			0,5	0,8
24				0,6
24				0,4
Stainless steel (Nitrogen)
Source power	1000 W	1500 W	3000 W	6000 W
Thickness, mm	Speed (m/min)
1	23,8	26,4	34	41,4
2	10,8	11,9	15,4	28,6
3	2,3	4,1	8,6	15,8
4	1,3	2,2	5,5	9,4
5	0,7	1,2	4,3	6
6		1	3,1	4,7
8			2	3,3
10			0,8	1,3
12			0,5	1,3
14				0,8
16				0,6
Aluminum (Nitrogen)
Source power	1000 W	1500 W	3000 W	6000 W
Thickness, mm	Speed (m/min)
1	8,4	16	34	42
2	3,4	6,6	15	25,5
3	1,4	3,8	7,6	14,6
4		1,4	4	5,8
5			3,3	4,9
6			2,1	4,1
8			0,9	2
10			0,6	1,7
12				0,8
14				0,6
16				0,5
Copper (Nitrogen)
Source power	1000 W	1500 W	3000 W	6000 W
Thickness, mm	Speed (m/min)
1	8	12	22	32
2	3,2	4	8	12
3	1	2,2	5,2	6,4
4		1,4	4	5,4
5			1,8	3,2
6			1,4	2,2
8			0,6	1,2
10				0,6
12				0,4
Brass (Nitgoren)
Source power	1000 W	1500 W	3000 W	6000 W
Thickness, mm	Speed (m/min)
1	7	10	22	35
2	2	4	12	20
3	0,5	1,8	5	12
4		1	3	9
5			2	6,5
6			1,3	3,8
8			0,6	1,8
10				1
12				0,7

High-tech equipment and verified accuracy are guaranteed

Protective cover

This protects MITSUBISHI servomotors, SHIMPO planetary gearboxes and HIWIN guide rails from external influences.
Protective cover laser head

This protects the main components of the laser head.
Rail with wires

The bus allows you to store electric cables for the movement of the gantry.
Protective chain for fibreglass

The chain protects the fibre-optic cable and wires for the laser head.
Pressure sensor

This controls and regulates the gas pressure for the laser head.
HIWIN bearings

The laser head is moved by Hiwin bearings. It provides smooth running, high load capacity and low noise.
MITSUBISHI Servomotors

MITSUBISHI's servo motors have smaller dimensions, double life, minimal vibration, gears up to 2G, easy replacement and maintenance.
SHIMPO planetary gearboxes

SHIMPO planetary gearboxes convert the torque from the servo motor and transmit it to the skew gear which drives the gantry and helps it move smoothly.
HIWIN guides

HIWIN guides have high precision and reliability, low friction and easy installation. They are synonymous with “reliability”. Rail guides shall be installed on the frame under expert supervision!
LEAN helical racks

Help the machine to withstand loads at the required speed and ensure smooth gantry movement. Helical racks shall be installed on the frame under expert supervision!

Purchase procedure

Equipment selection

We assist you in making your choice of a machine matching your needs
Sending invoice

We agree on the complete set of the machine and sending the invoice with the final cost of the equipment.
Payment

In full if the machine is in stock. 50% in advance 50% at the delivery if the machine is not in stock.
We check the machine

The 3 step quality control: at the Wattsan factory, at our warehouse in the Netherlands, before the delivery.
Delivery or pick-up

Either a transport company or you pick up the machine from our warehouse.
Launching equipment

We are here to assist you whenever you need support.

Laser head for your tasks

Wattsan metal cutters are equipped with laser heads from popular manufacturers such as Raytools, BOCI and Precitec.

1. QBH connector

  It is the link between the fiber optic cable and laser head. It prevents beam return thus protecting the laser source.
2. Collimator module

  Is is used for narrowing and adjusting the laser beam. It makes the laser beam suitable for further transmission to the focusing module. It should not be replaced more or less than once a year.
1. Focusing module with position controller

  Dynamically adjusts focal distance during operation to ensure deep and quality cuts.
2. Protective glasses

  Protective glasses protect expensive focusing optics against dust, dirt and sparks. The upper glass is rarely replaced. The lower protective glass is the main consumable.
3. Induction sensor

  It maintenances the correct nozzle height above the material which ensures a stale cut regardless of material curvature.
1. Ceramic nozzle adapter

  It protects the cutting head from heat generated during laser cutting.
2. Nozzle

  Ensures that the gas jet and laser beam are aligned for a better cut.

Experiences from enthusiastic bloggers

I’m extremely happy with the device! Its powerful reinforced frame reduces wobbling which is perfect for engraving at high speeds. I’ve been using it for acrylic glass and the results look really cool.

Heinrich Schüür
A great laser engraver, it can cut significant thicknesses of wood without effort. I used it for both engraving and cutting, and the machine worked wonderfully.

Il Makerstauratore
This laser engraver can engrave without any problem. How fast and easy it is able to customize products!

Riccardo Muscarella
Machine has a perfectly flat surface. It makes repetitive work easier for me!

Matteo Moras
Great job done within an hour. Thanks to the speed of the laser CO2 machine.

Roberto D'Adago
This model is great, and laser precision is crazy, it’s sharp as a razor!

Roger Jungo

Cabinet-type protection:: Yes

Working area:: 2000x4000/2000x6000/2000x8500 mm

Frame:: Metal sheet, Moulded with strengthening, Welded from thick-walled steel tube

Laser power:: 20000-120000 W

Laser head:: BOCI BLT 6

Laser type:: Raycus/IPG

Z Engine power W:: 750 W

XY Engine power:: 1300/3000 W

Structure of XY axis:: Guides HIWIN / Helical rack LEAN, 25 mm / 35 mm

Structure of Z axis:: HIWIN Guides 20 mm / Ball Screws 25 mm

Height sensor:: Automatic capacitive

Grease system:: Automatic centralized, semi-automatic

Max. movement speed:: 100/120 m/min

Max. working speed:: Depends on the material

Additional gas:: air, argon, nitrogen, Oxygen

Repositioning accuracy:: ±0.02 mm

Type of end sensors:: Inductive

Control system:: EtherCAT BUS FSCUT8000C

Automatic change of work tables:: Yes

Power electrics:: Siemens

Software:: FSCUT 8000

Height control system:: BCS100

Ask questions

A fiber-optic laser is best suited for cutting metal, but a specially equipped CO2 laser with a high-power laser tube may also be suitable for this purpose. However, it should be borne in mind that the thickness of the metal for cutting with a CO2 laser is limited to 1.5 mm, while a fiber-optic laser is capable of cutting up to 25 mm.
The cost of an hour of laser cutting depends not only on the power of the laser machine and the speed of its operation, but also on a number of other factors, such as: the professional skills of the machine operator, the cost of renting a production room, the cost and consumption of electricity, the cost of the material itself, the amount of scrap and downtime of the machine, and much more. In order to unambiguously answer the question about the cost of an hour of laser cutting, it is necessary to take into account all these parameters.
A focused laser beam is applied to the metal surface, as a result of which it melts, the molten material is blown out of the cutting zone with the help of an auxiliary gas.
The power of the laser emitter depends on the thickness of the material being processed and the desired processing speed. For example, a 1 kW emitter will cut 1 mm thick stainless steel at a speed of 13 m/min, and a 3 kW emitter will cut the same material at a speed of about 35 m/min. Here everything depends on the budget and the expediency of using the maximum possible capacity. Although it can be said that in today's competitive realities it does not make sense to buy a laser machine with a power of less than 1 kW.
